1. Cover more than 95% of the whole system of EVs, and keep updating!
2. Supports testing of DC/DC converter, onboard charger, high-voltage distribution box, and other common maintenance functions;
3. Provide four battery pack connection methods, including OBD, special connector, jumper connection, and fast charging port
connection;
4. Equipped with battery pack professional connector as standard and integrated aviation plug connector to improve detection efficiency;
5. Support ADAS calibration, tread detection, insulation tester, oscilloscope, digital power supply, multimeter, current clamp, video scope, and other expansion modules;
6. Dual will design, the host is connected to the VCl with independent Wif, and the VCl does not affect the host to access the network it is working;
7. Provide the whole vehicle topological graph, clearly display the vehicle communication network, and quickly locate the fault point.
| Functions | Description |
| Battery Pack Detection | support battery pack detection of passenger car and commercial vehicle battery brands, read soc/SoHmonomer/module voltage, temperature, battery pack status and fault information, and automatically calculate total voltage anddifferential pressure , key index data such as the highest/lowest voltage, and automatically mark abnormal data |
| Vehicle Detection | support the whole system and full-function detection of EVs, such as code reading, code clearing, data flowreading,action testing, and special functions |
| Fast Charging Port Detection | connect the fast charging detection gun with Bluetooth, and read the battery pack data through thefast charging port of the vehicle to realize fast detection of the battery pack |
| Maintenance Function | support offline testing of Dc-Dc converters, 0Bc car chargers, air conditioner compressors, 48v lighthybrid components,etc..and support 30+ common special functions |
| ADAS Calibration | supports ADAS system calibration of many models in Europe,America, Asia, and China, compatible with ADAsPRO+,ADAS MOBILE,ADAS LITE, ADAS RADAR 3INl and other equipment |
| Test Report | support the display of battery pack test report, vehicle test report, ADAs calibration report, etc |
| Software Upgrade | support online upgrades, including model software, firmware software, and App software |
| Module Expansion | support tread detection, digital power supply, osciloscope, multimeter, current clamp, insulation test,endoscope and other functional expansions |
Parameters
| Host |
| Display Size | 10.1inches(1920x1200) |
| CPU | 2.0GHz Octa-core |
| Memory | 4GB |
| Storage | 128GB |
| System | Android11 |
| Wi-Fi | 2.4GHz/5GHz |
| Camera | Front 8MP, Post 13MP |
| Battery | 3.8V/9360mAH |
| Interface | Type A, Type C |
| Communication | Wi-Fi, BT, USB |
| Product Size | 318×40.5×246.5mm |
| VCI |
| Voltage | DC9~36V |
| CPU | Cortex-A7 + Cortex-M7 |
| Memory | 256MB |
| Storage | 8GB |
| System | Linux |
| Wi-Fi | 2.4GHz/5GHz |
| Communication | Wi-Fi, BT, USB |
| Interface | USB Type B, OBDⅡ-16, DC-IN |
| Product Size | 197×40×83mm |
